Xinda Chemical, as a reliable manufacturer of polypropylene tank, can provide you with wholesale and customization services.The tank is made of high quality polypropylene (PP) raw material, and is formed by whole welding or winding process to ensure that the tank has no weld and no leakage, and has excellent overall structural strength and tightness. It can safely store the vast majority of acid, alkali, salt solutions and some organic solvents. Moreover, the material itself is non-toxic and odorless, meeting the hygiene standards of the food and pharmaceutical industries.
Compared with traditional metal storage tanks such as stainless steel, it fundamentally avoids the problems of corrosion and rusting, is lighter in weight, more convenient for installation and transportation, and has a design service life of over 15 years under normal temperature and pressure, with a remarkable comprehensive cost performance. We can provide a one-stop customized solution from design to production based on the specific medium you store, required capacity, working conditions and on-site installation space. It is a reliable choice for those who pursue safety, durability and economy.
Our polypropylene tank has excellent corrosion resistance. It is resistant to the vast majority of inorganic acids (hydrochloric acid, sulfuric acid, etc.), alkalis (sodium hydroxide, etc.), salt solutions and some organic solvents (such as ethanol, acetone), but it is not resistant to strong oxidants (concentrated nitric acid, chromic acid) and aromatic hydrocarbons (benzene, toluene).
The tank is made of food-grade PP material that meets hygiene standards (such as FDA certification) and can store soy sauce, pure water, pharmaceutical intermediates, etc.
The tank features light weight, high strength and economy. Its density is only 0.91 to 0.93g/cm³, and its weight is 1/5 to 1/8 of that of a steel tank of the same volume. It is easy to install and reduces the cost of the foundation. The thickness of the tank can be gradually designed (thickened to 60mm at the lower part where the force is greater), with high raw material utilization rate and better cost performance than stainless steel storage tanks.
Seamless winding forming: No weld seams, strong impact resistance, high overall strength, and a service life of up to 8 to 12 years.
Customization and flexibility: Supports vertical/horizontal, flat-bottom/conical bottom designs, with a volume range of 0.1 to 500 cubic meters. It can be equipped with functions such as stirring and heating jackets.
|
Parameter Item |
Parameter Value / Description |
|
Working Temperature |
-10℃ to 120℃ (standard)Short-term tolerance up to 130℃ |
|
Working Pressure |
Atmospheric pressure (-0.02 to 0.1 MPa)Specially designed to withstand low pressure (≤0.4 MPa) |
|
Impact Strength |
≥20 kJ/m² |
|
Tensile Strength |
≥30 MPa |
|
Other Key Performance |
Leak-proof, scale-resistant |
Our polypropylene tank can be applied in the chemical industry and is suitable for storing acid and alkali solutions, organic solvents, pesticide intermediates, etc.
The tank can be applied in the field of environmental protection and is suitable for chemical storage tanks in sewage treatment plants (PAC, PAM solutions) and circulating liquid tanks in waste gas treatment.
It can be applied in the chemical industry, food and medicine, and is suitable for food additives (citric acid, acetic acid), oral liquid preparations, and pure water storage.
It can be applied in the environmental protection field of metallurgy/electroplating, and can be used in acid washing tanks, electroplating solution storage, and the transfer of metal surface treatment waste liquid.
When selecting a Polypropylene Tank, the primary basis is the chemical properties, concentration and working temperature of the medium to be stored.For highly corrosive or large volumes (e.g., more than 50 cubic meters), polypropylene and FRP (PP+FRP) composite reinforcement structures are recommended to provide higher mechanical strength and long-term stability.
When installing, corresponding measures should be taken according to the type of storage tank. Horizontal storage tanks should be installed on saddle supports that have been calibrated horizontally to ensure uniform load-bearing, while vertical storage tanks need to be fixed with a solid concrete foundation. It is recommended that all pipe connections use flexible joints in combination with corrosion-resistant gaskets (such as EPDM) to buffer the stress caused by thermal expansion and contraction.
Daily maintenance is the key to ensuring the long service life of equipment.The tank should be inspected visually regularly for abnormal deformation or color change, and ensure that the sealing of each interface is intact.In order to avoid accelerated aging of plastic materials due to ultraviolet radiation, storage tanks should be placed indoors or equipped with sunshade as far as possible.In the need for internal cleaning, be sure to use soft tools, it is strictly forbidden to use metal brushes or shovel, so as not to scratch the inner wall and destroy its anti-corrosion performance.
